For Faster & Expansive Extraction
Buffalo Extraction Systems’ Level 2 and 3 Carbon dioxide Supercritical Fluid Extraction (CO2 SCFE) systems cater to medium and large scale extraction operations. As compared to Level 1 systems, these have larger extractor capacities and automated operation of the extractor changeover valves .
Operator convenience is an integral part of these ergonomically designed systems that come with an intuitive user interface. Safety automation, rapidly opening closures, and automatically working extractor changeover valves guarantee highest possible productivity with minimal downtime .
Level 2 and Level 3 CO2 SCFE System: Technical Specifications
Ergonomics is built into the Level 2 and 3 systems making it simple and comfortable for personnel to handle them. An intuitive user interface provides a single interface operation to monitor the values of all the parameters in the system. Personnel can supervise the process at all times.
Table 1 lists out the technical specifications of the Level 2 and 3 Carbon dioxide (CO2) Supercritical Fluid Extraction (SCFE) systems.
|Parameter||Level 2 Specification||Level 3 Specification|
|Volume of Single Extractor||25 / 50 Litre||100 / 200 / 500 Litre|
|Number of Extractors||2 / 3||2 / 3|
|Usage of Extractors||Single / Series||Single / Series|
|Pressure||350-650 Bar / 5000-9000 PSI||350-650 Bar / 5000-9000 PSI|
|Temperature||70-110 0C / 158-230 0F||70-110 0C / 158-230 0F|
|Extractor Changeover Valves||Automatic||Automatic|
|Flow Rate of CO2 Pump||40-80 LPH||40-80 LPH|
|CO2 Feeding & Recovery System||Included||Included|
|Certifications||CE / U1 / U2 / cGMP
ASME-BPE / UL / SIL-3
|CE / U1 / U2 / cGMP
ASME-BPE / UL / SIL-3
Table 1. Technical Specifications of Buffalo Extraction Systems’ Level 2 and 3 Supercritical Fluid Extraction (SCFE) System
Incorporating innovation through close process parameter control, superior ergonomics, rapid changeover mechanisms, and ingrained focus on safety, Buffalo Extraction Systems lends an innovative dimension to the already fantastic proficiency of carbon dioxide supercritical fluid extraction.
Buffalo Extraction Systems amplifies the great capabilities of the Carbon dioxide Supercritical Fluid Extraction process and places fantastic deliverables at your disposal.
Write to us at firstname.lastname@example.org and get a first hand feel of genuine innovation at work.
